          KELLENBERGER 1000 U KELLENBERGER 1000 U KELLENBERGER 1000 U KELLENBERGER 1000 U KELLENBERGER 1000 U
          KELLENBERGER 1000 U
          KELLENBERGER 1000 U KELLENBERGER 1000 U KELLENBERGER 1000 U KELLENBERGER 1000 U

          KELLENBERGER 1000 U

          700000 INR/Piece

          Product Details:

          • Voltage 380-440V 3-Phase
          • Origin Switzerland
          • Power Approx. 5-7.5 kW
          • Used For Cylindrical and Surface Grinding applications
          • Machine Type Universal Grinding Machine
          • Feature Precision Grinding; Universal Application
          • Output High-quality grinding finish
          • Click to View more
          X

          KELLENBERGER 1000 U Price And Quantity

          • 700000 INR/Piece
          • 1 Piece

          KELLENBERGER 1000 U Product Specifications

          • Switzerland
          • Approx. 5-7.5 kW
          • 380-440V 3-Phase
          • Universal Grinding Machine
          • Cylindrical and Surface Grinding applications
          • Precision Grinding; Universal Application
          • High-quality grinding finish
          • Approximately 2500 kg
          • No Warranty (used machine)
          • Used
          • 2000 x 1200 x 1600 mm
          • Light Gray

          Product Description

          MODEL - 1000U

          Distance between centres - 1000 mm

          Grinding diameter - 480 mm

          Grinding wheel:     Diameter - 400 mm

          Width - 50 mm

          Spindle taper (collets) - B32

          Spindle taper - 5 MT Taper in tailstock - 3 MT

           Voltage - 50 Hz 3x 380 Volt

          External Grinding wheel motor - 4.0 HP

           Workhead spindle motor - 2.0 HP

          Total power required - 8.4 HP

          Machine's weight about - 2200 kg

          Overall dimensions machine:

          Length - 3000 mm

          Width - 1700 mm

          Height - 1400 mm
